MW500

MW500 – Motor Drive

Variable Speed Drives – MW500 G2

Power supply: 200 – 240 V single-phase or 380 – 480 V three-phase Rated output current: 1.3 to 16 A Rated output power: 0.37 to 7.5kW (0.5 to 10HP) Built-in SoftPLC in the standard product Low harmonic distortion Aluminium frame NEMA 4X / IP66 protection degree Built-in analog potentiometer for speed reference Dedicated PTC Operation indicator LED Indoor or outdoor applications Switch-disconnector (Optional) Mounted in electric panel, wall or motor surface W22 line

MW500 G2 – Decentralized – Motor Drive

The MW500 is a high performance product dedicated for induction motor control, with embedded features and a high protection degree of IP66 / NEMA 4X which allow decentralized installation directly on the motor or on a wall. Designed exclusively for industrial or professional use, the decentralized WEG VSD adds a great deal of flexibility, allowing the user to install the product near to the controlled motor, thus eliminating the necessity of long cables and panels.

Versatile

The MW500 is an inverter with IP66 rating and special mounting characteristics for environments that require high degree of protection. It offers VVW vector or V/F scalar control and can be vertically mounted in electric panels, on the wall and directly to the motor surface W22 line.

Applications

• Centrifugal pumps
• Process pumps
• Mixer / bottlers
• Conveyor belts
• Compressors
• Fans / exhausters
• Washers / dryers
• General machinery
• Etc
