CFW500

Variable Speed Drives – CFW500

Power supply: 200 – 240V, 380 – 480V or 500 – 600V Rated output current: 1.0 to 211 A Rated output power: 0.25 to 132kW (0.33 to 175HP) Voltage vector control VVW – Voltage Vector WEG, and vector with or without encoder (sensorless) and VVW PM permanent magnet motor control. Software applications dedicated to pumping – Pump Genius Plug & Play control Built-in SoftPLC Free WPS programming and monitoring software Smart thermal management of the fan LCD operating interface (HMI) with backlight RFI filter according to the levels of EN 61800-3 standard (Optional, available by means of accessories) Comminication protocols: CANopen, Device Net, Profitbus-DP, EtherNet/IP, ModBus-TCP, ProfiNet-IO, RS485 and RS232 (Optional, available by means of accessories) Flash memory module (Optional, available by means of accessories), enabling the data and transfer (parameter and applications) between inverters without turning them on

CFW500 – Machinery Drives

Develop for fast commissioning, the CFW500 is perfect for machines. Extremely compact and cost-effective, it fulfils the needs of machine manufacturers, integrated systems, panel installer and user for a wide range of applications.

SoftPLC – Built-in on the Standard Product

It adds the functionalities of a PLC to the CFW500. Allowing the creation of applications. The WLP software and the SoftPLC functionality are a smart and simple way to make your CFW500, motor and application work together.

SuperDrive G2

Software application for programming, command and monitoring of WEG VSD.

• Trace function; On-line graphic monitoring of parameters/variables
• Status monitoring; real time monitoring
• Editing of parameters in List/Table; Off-line editing of the parameters stored on the PC

Applications

• Extruders
• Conveyor belts
• Roller table
• Fan / exhausters
• Centrifugal pumps
• Granulators / palletizers
• Dryers and rotary ovens
• Process dosing pumps
• Mixers / stirrers
• Rotary filters
• Winding / uncoiling machines
• Etc
